HDPE Geocell

Geocell is a confinement system that performs better than conventional crushed stone sections, and it provides an expedient construction technique for access roads over soft ground without being adversely affected by wet weather conditions. Geoeell can also be used to strengthen paved areas.

Geocells are efficient and economical for fast-built unpaved roadways and retaining walls, erosion control of slopes, and stormwater control in channels.

GeoCell is a confinement system that performs better than conventional crushed stone sections, and it provides an expedient construction technique for access roads over soft ground without being adversely affected by wet weather conditions. GeoCell can also be used to strengthen paved areas.

  • Material: High Density Polyethylene (HDPE)
  • Color: Black
  • Surface: Textured
  • Sheet Thickness: 1.5mm
  • Welding Space:  300mm to 1000mm
Category:

HDPE Geocell



  • ♦ HDPE Geocell is engineered for soil stabilization applications, it is used to help improve the performance of standard construction materials and erosion-control treatments.



  • ♦ HDPE Geocell is a lightweight and flexible three-dimensional, expandable panels made from high-density polyethylene (HDPE) strips which are ultrasonically bonded together to form an extremely strong configuration. HDPE Geocell System can be filled with a wide range of material: aggregate, concrete, sand, soil, etc.





Application：

  • *Erosion Control
  • *Load Support
  • *Slope Protection
  • *Channel Protection
  • *Retaining Wall
  • *Ground Stabilization





Specification



SpecsTest MethodUnit

Value

1

Welding SpaceMm

356

2

Cell Depthmm

150

3

Sheet ThicknessASTM D5199Mm

≥1.5

4

Seam Peel StrengthN

≥1500

5

Carbon Black ContentASTM D1603%

≥1.5

6

Yield strength of CellASTM D6693N/Mpa

≥20

7

Coefficient of thermal expansionPMM/°C

<150

8

Elastic(dynamic) Modulus(DMA)at 30°C

Elastic(dynamic) Modulus(DMA) at 45°C

Elastic(dynamic) Modulus(DMA) at 60°C

ASTM E2254Mpa>750

>650

>500

9

OXIDATION-INDUCTION TIMEASTM D3895Min

>150

Note: Cell depth can be from 75mm to 200mm,Welding Space can be from 300mm to 1000mm.



Material

High Density Polyethylene

Density

0.94g/cm3

Surface

Textured HDPE Geocell
